Replacing a clubhead or the shafts of your clubs does not require you to send your clubs to be refitted. As long as you follow the correct instructions for removing and cleaning the shaft and clubhead you can fit the shafts or clubhead yourself. That is, provided you use the best epoxy for golf clubs.
The most important aspect in replacing a shaft is in selecting and applying the correct epoxy. If you have ever had a club head flying off while playing a round of golf or at the driving range then you know the importance of epoxy for golf clubs.
- What is an Epoxy for Golf Clubs?
- Types of Epoxy used for Golf Clubs
- Golf Club Epoxy vs. General-Purpose Epoxy
- Curing of Golf Club Epoxy
- Best 4 Epoxy Adhesives for Golf Clubs
What is an Epoxy for Golf Clubs?
A golf club epoxy is an organic compound that is a type of glue that can be used on golf clubs, to attach a shaft to the clubhead. Knowing how to use a golf club epoxy can be beneficial when your clubs need a quick repair job.
There is a wide range of epoxy adhesives available in the market that are designed to meet a wide range of requirements. These epoxies must be durable, capable of withstanding heavy loads and pressures, chemical, heat and, water-resistant.
Types of Epoxy used for Golf Clubs
Epoxy adhesives for golf clubs can either be a quick cure epoxy or a long cure. Both adhesives are two-component based. Normally an equal quantity of each component is mixed together.
A tip to making the epoxy stronger and increase the strength and adhesion is to add glass shafting beads. A small pinch of these beads will help increase not only strength but will help center your golf shaft in the hosel.
This video will give you more insight into using epoxy on golf clubs.
The time taken for curing depends on the type of epoxy used and the temperature at which it is used.
A quick-cure is recommended only for emergency repairs such as if you need to use your golf club within an hour or two. It is often referred to as the five-minute epoxy. It tends to have lower overall shear strength and have very short mix times
A long cure epoxy or twenty-four-hour epoxy takes six to seven hours to set. It is 90% cured after twenty-four hours and 100% cured after seven days. You can use the club after twenty- four hours of curing.
Golf Club Epoxy vs. General-Purpose Epoxy
Most epoxies will do the intended job but non-golf or General- purpose epoxies that can be purchased at any hardware store, are not recommended. They are not engineered specifically to withstand the unique forces generated by the golf swing. They tend to be brittle resulting in poor peel and impact resistance.
It is thus recommended that you use epoxy, designed specifically for golf. They usually have higher peel shear strengths and elastic properties that can withstand the specific forces encountered during a golf swing.
Ideally, your golf epoxy should have a minimum psi rating of 2500 psi
Curing of Golf Club Epoxy
The temperature of the room where the epoxy is being applied and where it will be left to cure is critical to ensure that the epoxy cures properly.
Temperatures should not be lower than 65 degrees Fahrenheit and never exceed 135 degrees Fahrenheit. The ideal temperature is between 70 and 90 degrees Fahrenheit. In warmer weather, the epoxy could dry in twelve to eighteen hours. This is not always advisable as it could affect the strength and durability of the epoxy.
The epoxy will not cure if the two components consisting of a resin and, curing agent have not been mixed to the ratio recommended for that product. Ensure that the hosel and shaft have been cleaned properly.
Quick Overview: Our Top Picks for 4 Epoxy For Golf Clubs
|J-B Weld 8281||VIEW ON AMAZON →|
|Brampton Epoxy PRO-FIX||VIEW ON AMAZON →|
|GolfWorks High Strength Epoxy||VIEW ON AMAZON →|
|Permabond Epoxy For Golf Clubs||VIEW LATEST PRICE →|
Best 4 Epoxy Adhesives for Golf Clubs
With our choice of the best epoxy adhesive, we are only reviewing the long-cure epoxies as these will guarantee a strong long-term fitting of the shaft.
1. J-B Weld 8281 Professional-Size Steel Reinforced Epoxy Twin Pack – 10 oz
The J-B Weld 8281 has a very high tensile strength of 5020 psi that can withstand all the forces exerted from swinging a golf club.It is resistant to acid, water and, cracking from high impact and is very durable and, has a high heat tolerance
This Twin-Pack has a mix ratio of 1;1 and is set within 4 to 6 hours and cures within 15 to 24 hours to allow for strong bonding.
2. Brampton Epoxy Pro-Fix 20/20 Long Cure Golf Club Repair
The Pro-Fix 20/20 has a Superior Bond Strength developed with strong resistance and durability that will adhere to all shafts including graphite, steel, and, titanium. It is guaranteed to set with a hard bond within 20 – 30 minutes and takes 20 hours to cure.An easy-squeeze bottle is included with the 4oz and 8oz packs. An easy-to-dispense double barrel cartridge with a 0.85 oz 1: 1 mix ratio by volume is included.
The ProFix 20/20 has an Aerospace Grade Bond Strength of 5800 psi nominal bond strength and is sturdy enough for golf swings over 120 mph.
By following the 8 step instruction process it is easy to replace clubheads or fit new shafts. The ProFix 20/20 is specially formulated to easily remove heads without damaging the graphite shaft.
3. GolfWorks High Strength Epoxy Golf Club Head Shaft Adhesive 50 ml
- Brand: The Golf Works
- Package Information: Cartridge Tube
- Volume: 50 ml
Golf Works High Strength Epoxy is formulated for Clubmakers. It creates a very strong bond with a high shear strength for very high torque resistance.
The High Strength Epoxy is a two-component based epoxy that is mixed to a ratio of 1:1. That sets in 18 hours and cures in 24 hours.
The epoxy is available in a 50ml cartridge for easy application. A thumb plunger is included with each tube to eliminate the need for an epoxy dispensing gun.
4. Permabond Epoxy For Golf Clubs
The benefits of using Permabond two-part epoxies are:
- Easy mixing from the cartridge( various sizes dependant on the product used) with a static mixing nozzle.
- Cures at room temperature.
- Water and heat resistance.
- Available in bulk for high-speed production lines manufacturing golf clubs.
- Is resistant to the high impact encountered from a golf club swing and has a high peel and shear strength.
- Have psi ratings of more than 2500 psi.
Permabond has been supplying two-part epoxies to the golf industry for many years and is a reputable CompanyPerabond offers a range of epoxy adhesives that are suitable for bonding golf clubs with graphite, steel, and, titanium shafts.
If the steps required to fit a shaft to a clubhead are followed correctly then you can easily and correctly fit your selected shafts without having to send them in to be fitted thus saving you unnecessary costs.
In our assessment, the GolfWorks High Strength Epoxy is the recommended Epoxy for replacing your golf shafts or a clubhead.
Please add your feedback in the comments section below.
